Name: Ink Temperature Controller for printing machine
Brand: Qingdao ZFC Trading Co.,Ltd
SKU: Reco100, Reco150, Reco200
Availability: InStock

Inicio Productos Sistema de control de la temperatura de la tinta

Ink Temperature Controller for printing machine

Datos del producto:

Lugar de origen:	Porcelana
Nombre de la marca:	REX
Número de modelo:	Reco100, Reco150, Reco200

Pago y Envío Términos:

Cantidad de orden mínima:	un juego
Detalles de empaquetado:	caja de madera
Tiempo de entrega:	15 días laborables
Condiciones de pago:	T/T
Capacidad de la fuente:	30 set por mes

Contactar ahora

Descripción detallada del producto

Temperatura de funcionamiento:	+10~40℃	Rango de temperatura de la solución humectante.:	25℃
Refrigerante:	R22, R134a, R407c, R404a

Ink Temperature Controller for printing machine

Ink Temperature Controller for printing machine

1.Ink Temperature Controller Reco100
Defined mechanical, electrical and fluid interfaces	380v 50Hz 3PH
Qualified Quality system	ISO9001:2008 GB/T 19001-2008
Environment
Operating temperature	+10~40℃
Temperature for transport	Up to 65 °C
Operating relative humidity (not condensing)	30 – 95%
Geographic height with air cooled refrigeration unit	Under 3000m
System Specification
Temperature range of the dampening solution	25℃
Cooling Capacity	-
Refrigerant	R22, R134a, R407c, R404a
Flow Rate	-
Water quality fresh water	8dH
Water temperature fresh water	Max. 25°C
Dimension (mm)	≤L1350×D850×H1730
Net Weight(KG)	280KG
Gross Weight(KG)	300KG

2.Ink Temperature Controller RECO150 for Manroland 705 3B LV(74X104CM) printing machine
Items	Value we are offering
completely pre-assembled, wired and tested	Power Supply; Water Supply
mechanical, electrical and fluid interfaces	380v50Hz 3PH
Operating Voltage	361V~415V 50Hz 3ph
Qualified Quality system	ISO9001:2008 GB/T 19001-2008
Operating temperature	-5~40℃
Operating relative humidity	30 - 95%
Temperature range for water feeding	10~30°C (setting 25℃ in the factory)
Cooling capacity	10748kcal/h R134a
Flow rate	≥6T/H
Water quality fresh water	8-14°dH
Water temperature fresh water	Max. 25°C
Dimension	L1550×D850×H1700
Net Weight	320Kg
Gross Weight	350Kg

3.Ink Temperature Controller Reco200 has same specification as Digiller 3.
Items	Value we are offering
completely pre-assembled, wired and tested	Power Supply; Water Supply
Operating Voltage	380V 50Hz 3PH
Qualified Quality system	ISO9001:2008 GB/T 19001-2008
Environment
Operating temperature	-15~40℃
Temperature for transport	Up to 65℃
Operating relative humidity	30 - 95%
Geographic height with air cooled refrigeration unit	Under 3000M
System Specification
Temperature range of the dampening solution	5~14°C
Water Quality Fresh Water	8~14° dH
Water temperature Fresh Water	Max. 25°C
Cooling capacity	32Kw, 109500Btu/H
Dimension	L1650×D900×H11830
Net Weight	350Kg
Gross Weight	380Kg

4.Digital Press Temperature Controller Digiller5 for HP Indigo10000/20000 Series

Items	Value we are offering
Digiller5 Digital press temperature control system
General requirement
completely pre-assembled, wired and tested	Finished machine; Connect the water pipes and connect to the power supply at the customer's factory.
Defined mechanical, electrical and fluid interfaces	Power supply:380v50Hz 3PH Standard Output flow/Backflow
Required Industrial standard	JB/T 11123-2010
Qualified Quality system	ISO9001:2008 GB/T 19001-2008
Degree of protection electrical Connections	IP54

Environment
Operating temperature	-5~40℃
Temperature for transport	Up to 65 °C
Operating relative humidity (notcondensing)	30- 95%
Geographic height with air cooledrefrigeration unit	≤ 3000m

System Specification
Temperature range of thedampening solution	5~15 °C ( Setting 7°C before delivery)
Cooling capacity	≥50Kw
Water quality fresh water	8-14°dH
Water temperature fresh water	Max. 25°C
Dimension (mm)	L2000×D950×H2000
Net Weight	650KG
Gross Weight	700KG
Integrated dampening solution tank	≥400liters
* Filter system
Inlet fresh water	Standard
water pump pressure	6Bar
Water flow	110Liters/min
